Schneider MN undervoltage release, ComPact NS630b to NS3200 fixed, MasterPact NT/NW, rated voltage 200/250 VDC, 200/250 VAC 50/60 Hz 33671
This is a MN undervoltage release for Compact NS 630b to Compact NS 3200 devices. Its rated voltage is 200VDC to 250VDC [...]
Model :33671
SKU :
This item cannot be returned or exchanged
Cash on Delivery available
- Condition: New
Description for Schneider MN undervoltage release, ComPact NS630b to NS3200 fixed, MasterPact NT/NW, rated voltage 200/250 VDC, 200/250 VAC 50/60 Hz 33671
This is a MN undervoltage release for Compact NS 630b to Compact NS 3200 devices. Its rated voltage is 200VDC to 250VDC or 200VAC to 250VAC 50/60Hz. It is an auxiliary used for emergency off or remote opening applications. This auxiliary opens the circuit breaker when the control voltage drops to a value below 35% of its rated voltage Un. It complies with IEC 60947-2 standard. Compact NS 630b to Compact NS 3200 device can be equipped with 1 MX or 1 MN auxiliary.
Specifications
| Range | ComPacT |
|---|---|
| Range of product | ComPacT NS630b...1600 new generation ComPacT NS1600b...3200 new generation |
| Device short name | MN |
| Product or component type | Voltage release |
| Device application | Control |
| Voltage release type | Opening coil Undervoltage release |
| Control type | Standard |
| [Uc] control circuit voltage | 200...250 V AC 50/60 Hz 200...250 V DC |
| Circuit breaker mounting mode | Fixed |
| Range compatibility | ComPact (ComPact NS630b...1600) ComPact (ComPact NS1600b...3200) |
| Operating threshold | 0.35...0.7 x Un opening 0.85 x Un closing |
|---|---|
| Response time | 90 ms +/- 5 % for Compact NS630b...1600 90 ms +/- 5 % for Compact NS1600b...3200 40 ms +/- 5 % for MasterPact NT 90 ms +/- 5 % for MasterPact NW |
| Supply holding power | 4.5 VA |
| Accessory / separate part category | Spare part for MasterPact NT Spare part for MasterPact NT NAVY Spare part for MasterPact NW Spare part for MasterPact NW NAVY Spare part for ComPacT NS630b...1600 new generation Spare part for ComPacT NS1600b...3200 new generation |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.5 cm |
| Package 1 Width | 6.0 cm |
| Package 1 Length | 8.1 cm |
| Package 1 Weight | 150.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 9.0 cm |
| Package 2 Width | 13.0 cm |
| Package 2 Length | 18.5 cm |
| Package 2 Weight | 1.6 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 120 |
| Package 3 Height | 30.0 cm |
| Package 3 Width | 30.0 cm |
| Package 3 Length | 40.0 cm |
| Package 3 Weight | 19.435 kg |
| Warranty | 18 months |
|---|
