Schneider Electric EasyPact Circuit breaker CVS - CVS160B 25kA 380/415V TMD 3p/3d LV516622
EasyPact Circuit breaker CVS - CVS160B 25kA 380/415V TMD 3p/3d
Model :LV516622
SKU :LV516622
![Assured](image/tt/assured-sm.png)
- Condition: New
Description for Schneider Electric EasyPact Circuit breaker CVS - CVS160B 25kA 380/415V TMD 3p/3d LV516622
Schneider Electric EasyPact Circuit breaker CVS - CVS160B 25kA 380/415V TMD 3p/3d LV516622
Specifications
Range | EasyPact |
---|---|
Product name | EasyPact CVS |
Device short name | CVS160B |
Product or component type | Circuit breaker |
Device application | Distribution |
Poles description | 3P |
Protected poles description | 3D |
Earth leakage protection (Vigi add on) | Without |
[In] rated current | 125 A at 50 °C |
Network type | AC |
Utilisation category | Category A |
[Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
Trip unit name | TM-D |
Trip unit technology | Thermal-magnetic |
Trip unit rating | 125 A at 40 °C |
Protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
[Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
---|---|
Network frequency | 50/60 Hz |
Breaking capacity code | B |
[Ics] rated service breaking capacity | 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
Mechanical durability | 25000 cycles |
Electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 |
Control type | Toggle |
Long time pick-up adjustment type Ir | Adjustable |
long time pick-up adjustment range | 0.7...1 x In |
long time delay adjustment type | Fixed |
Short-time delay adjustment type | Fixed |
Instantaneous pick-up adjustment type Ii | Fixed |
Instantaneous pick-up adjustment range | 1250 A |
Contact position indicator | Yes |
Mounting mode | Fixed |
Mounting support | Backplate |
upside connection | Front |
Downside connection | Front |
Connection pitch | 35 mm |
Compatibility code | CVS160 |
Width | 105 mm |
Depth | 86 mm |
Height | 161 mm |
Standards | EN 60947-2 IEC 60947-2 |
---|---|
Product certifications | IEC GOST |
Electrical shock protection class | Class II |
Ambient air temperature for operation | -25…70 °C |
Ambient air temperature for storage | -50…85 °C |
