Schneider Electric Easypact EZC100H Circuit breaker TMD 40A 1 pole 1d EZC100H1040

Easypact EZC100H Circuit breaker TMD 40A 1pole 1d
Model :EZC100H1040
SKU :EZC100H1040
Assured
  0 reviews / Write a review
No Return 7 days retun policy available
Cash on Delivery Cash on Delivery available
AED 104.00
Rate inclusive of VAT
Sold By : MEPKart
Fulfilled by Thomsun Industries
100%
- +
Bulk Order
  •  Condition: New

Description for Schneider Electric Easypact EZC100H Circuit breaker TMD 40A 1 pole 1d EZC100H1040

Schneider Electric Easypact  EZC100H Circuit breaker TMD  40A  1 pole 1d EZC100H1040

EasyPact EZC100H is a 1 pole fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 25kA rms at 240VAC 50/60Hz. The operational voltage is 415VAC 50/60Hz or 125VDC. The rating of the thermal-magnetic trip unit is 40A. The trip unit provides fixed overload and instantaneous protections. The dimensions for this 1 pole version are 25mm (W) x 130mm (H) x 60mm (D). Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications.

Specifications

Main
Range of productEasyPact
Product or component typeCircuit breaker
Device short nameEasypact EZC100H
Circuit breaker nameEasypact EZC100H
Device applicationDistribution
Poles description1P
Protected poles description1t
Network typeDC
AC
Network frequency50/60 Hz
[In] rated current40 A at 40 °C
[Ui] rated insulation voltage690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage6 kV conforming to IEC 60947-2
[Ue] rated operational voltage125 V DC conforming to IEC 60947-2
415 V AC 50/60 Hz conforming to IEC 60947-2
Breaking capacity codeH
Breaking capacity10 kA Icu at 125 V DC 1P conforming to IEC 60947-2
25 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
5 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2
5 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity5 kA at 125 V DC conforming to IEC 60947-2
12.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
Suitability for isolationYes conforming to IEC 60947-2
Utilisation categoryCategory A
Trip unit nameTM-D
Trip unit technologyThermal-magnetic
Trip unit rating40 A at 50 °C
Protection typeShort-circuit protection
Overload protection
Pollution degree3 conforming to IEC 60664-1
3 conforming to IEC 947-1
Complementary
Control typeToggle
Mounting modeFixed
Mounting supportBackplate
upside connectionFront
Downside connectionFront
Mechanical durability8500 cycles
Electrical durabilityCategory A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
Connection pitch25 mm
Local signallingPositive contact indication
Neutral protection settingWithout protection
Earth-leakage protectionWithout
Height130 mm
Width25 mm
Depth60 mm
Environment
StandardsJIS C8201-2-2
EN/IEC 60947-1
GB/T 14048.2
EN/IEC 60947-2
IP degree of protectionIP20 conforming to IEC 60529
IK degree of protectionIK07 conforming to IEC 62262
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-35…85 °C
