Schneider Double Pole Switch with LED, AvatarOn C, 45A, 250V, 1 Gang, White - E8731D45N_WE
Model :E8731D45N_WE
SKU :E8731D45N_WE
7 days retun policy available
Cash on Delivery available
- Condition: New
Description for Schneider Double Pole Switch with LED, AvatarOn C, 45A, 250V, 1 Gang, White - E8731D45N_WE
Enhance control and visibility with the Schneider AvatarOn C Double Pole Switch in White. Model E8731D45N_WE is designed to handle up to 45A at 250V and features an LED indicator for easy operation. Ideal for both residential and commercial applications, this 1 gang switch offers both reliability and a sleek, modern aesthetic.
Specifications
AvatarOn C Switch Specifications
| Specification | Details |
|---|---|
| Main | |
| Range of product | AvatarOn C |
| Product or component type | Switch |
| Device application | Control |
| Colour tint | White |
| Complementary | |
| Device presentation | Complete product |
| Rated current | 45 A at 250 V AC 50/60 Hz |
| Switch function | 2-pole |
| Number of gangs | 1 gang |
| Number of rocker | 1 |
| Connections - terminals | Screw terminal |
| Local signalling | With light indicator, LED |
| Material | PC (polycarbonate) |
| Device mounting | Surface, Flush |
| Width | 86 mm |
| Height | 86 mm |
| Depth | 35 mm |
| Embedding depth | 21.2 mm |
| Environment | |
| IP degree of protection | IP20 |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.7 cm |
| Package 1 Width | 8.6 cm |
| Package 1 Length | 8.6 cm |
| Package 1 Weight | 147.5 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 8 |
| Package 2 Height | 9.3 cm |
| Package 2 Width | 12.5 cm |
| Package 2 Length | 26.5 cm |
| Package 2 Weight | 1.275 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 72 |
| Package 3 Height | 29.2 cm |
| Package 3 Width | 29.8 cm |
| Package 3 Length | 39.8 cm |
| Package 3 Weight | 12.075 kg |
