Schneider Contactor,EasyPact TVS,3P(3NO),AC-3,<=440V,40A,230V AC coil LC1E40P7
EasyPact TVS contactor 3 poles for motor applications up to 40A 22kW@440V. It provides a 230V 50/60Hz AC coil, without built-in [...]
Model :LC1E40P7
SKU :
This item cannot be returned or exchanged
Cash on Delivery available
- Condition: New
Description for Schneider Contactor,EasyPact TVS,3P(3NO),AC-3,<=440V,40A,230V AC coil LC1E40P7
EasyPact TVS contactor 3 poles for motor applications up to 40A 22kW@440V. It provides a 230V 50/60Hz AC coil, without built-in auxiliary contacts, power and control connections by screw clamp terminals. 75mm width for standard operating rates up to 1200 cycles per hour. It procures standard reliability and durability with 0.9 Mcycles electrical durability AC-3 and 5 Mcycles mechanical durability. It can cover -5°C to 55°C working temperature and mounted by DIN-rail, No derating up to 3000m altitude. Multi-standards certified (IEC, CCC, EAC) and Green Premium compliant (RoHs/Reach).
Specifications
| Range | EasyPact |
|---|
| Tightening torque | Control circuit: 1.2 N.m Power circuit: 5 N.m |
|---|
| Permissible ambient air temperature around the device | -20…70 °C at Uc -60…80 °C storage -5…55 °C operation |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.5 cm |
| Package 1 Width | 12.5 cm |
| Package 1 Length | 13.0 cm |
| Package 1 Weight | 981.0 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 9 |
| Package 2 Height | 15.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 9.116 kg |
