Schneider 20A 4Gang 1way switch-onindicator WhitePlate WhiteSurround E8434/1-WW
Model :E8434/1-WW
SKU :
This item cannot be returned or exchanged
Cash on Delivery available
- Condition: New
Description for Schneider 20A 4Gang 1way switch-onindicator WhitePlate WhiteSurround E8434/1-WW
Specifications
| Range | ZENcelo |
|---|---|
| Product or component type | Switch |
| Switch function | 1-way |
| Device application | Control |
| Number of gangs | 4 gangs |
| Device mounting | Flush Surface |
|---|---|
| Clamping connection capacity | 3 x 2.5 mm² for solid cable(s) 3 x 2.5 mm² for stranded cable(s) 4 x 1.5 mm² for solid cable(s) 4 x 1.5 mm² for stranded cable(s) |
| Rated current | 20 A at 250 V AC 50/60 Hz |
| Local signalling | Mechanical indicator (amber) |
| Material | Grid plate: polycarbonate + GF 20 % Base: polycarbonate Cover: polycarbonate Surround: polycarbonate |
| Load type | Inductive Fluorescent lamp Resistive Incandescent lamp |
| Colour tint | white (RAL 9003) |
| Cover frame colour tint | White |
| Connections - terminals | Brass rod terminals |
| Width | 87 mm |
| Height | 87 mm |
| Depth | 31 mm |
| Ambient air temperature for operation | -5…35 °C |
|---|---|
| Relative humidity | 0…95 % |
| Environmental characteristic | No UV resistant |
| Operating altitude | 2000 m |
| Standards | SS 227-1 MS IEC 60669-1 GB 16915.1 IEC 60669-1 EN 60669-1 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.7 cm |
| Package 1 Width | 8.7 cm |
| Package 1 Length | 3.1 cm |
| Package 1 Weight | 0.001 g |
