ABB Residual Current Circuit Breaker, 2 Pole, 100mA, 25A - FH202-AC-25-0-1

Description for ABB Residual Current Circuit Breaker, 2 Pole, 100mA, 25A - FH202-AC-25-0-1

The ABB FH202-AC-25-0-1 Residual Current Circuit Breaker (RCCB) offers superior protection for people and electrical installations by detecting and interrupting fault currents to earth. Engineered for domestic applications, this RCCB provides reliable earth fault protection with a rated residual current of 100mA. Built to withstand impulses up to 4 kV, it has a rated current of 25A and operates efficiently within a -5°C to 40°C temperature range. With a compact white design measuring 35 x 69 x 85mm, it seamlessly integrates into standard setups, offering dependable safety.

Specifications:

• Model: FH202-AC-25-0-1
• Part Number: 2CSF202006R2250
• Rated Current: 25A
• Color: White
• Wattage: 1W
• Dimensions: 35 x 69 x 85 mm
• Frequency: 50-60Hz
• Rated Residual Current: 100mA
• Operating Temperature: -5°C to 40°C
• Storage Temperature: -40°C to 70°C
• Brand Origin: Germany
