ABB Modular USB Charging Socket With Half/Double Rocker Frame, Millenium, 2 Module, 2 Gang, 1.5A, 2 Pcs/Set - AMD85144-AN-plus-AMD5144-WG

Description for ABB Modular USB Charging Socket With Half/Double Rocker Frame, Millenium, 2 Module, 2 Gang, 1.5A, 2 Pcs/Set - AMD85144-AN-plus-AMD5144-WG

The ABB AMD85144-AN USB Charging Socket is designed to bring modern, efficient charging into any space. With an input voltage range of 100-240 VAC and a 5 VDC output, this socket provides a total current of 1.5A across two gangs, perfect for quick and convenient charging of multiple devices. Made from robust thermoplastic in an anthracite color, the socket is built for flush-mounted installation, blending seamlessly into walls. The USB socket is paired with the stylish ABB AMD5144-WG Half/Double Rocker Frame in white glass, featuring a glossy stainless-steel finish that enhances any decor. Suitable for both horizontal and vertical orientations, this set combines high functionality with a sleek aesthetic for any residential or commercial space.

Key Features:

• ABB AMD85144-AN USB Charging Socket:

  • Input Voltage: 100-240 VAC ±10%, Input Frequency: 50/60 Hz
  • Output Voltage: 5 VDC ±5%, Output Current: 1.5A (combined for both gangs)
  • Standby Power Consumption: ≤ 0.3W@230VAC, Energy Efficiency ≥ 71%
  • Material: Thermoplastic, Color: Anthracite
  • Flush-mounted design for seamless integration
  • Dimensions: Width 76mm, Height 64mm, Length 76mm, Weight 0.078 Kg
  • Ambient Operating Temperature: -5 to 35°C

• ABB AMD5144-WG Half/Double Rocker Frame:

  • Color: White Glass with a glossy stainless-steel finish
  • Compatible with horizontal and vertical mounting orientations
  • Frame includes a metal mounting plate for added stability
  • Dimensions: Width 86mm, Height 86mm, Depth 4mm, Weight 0.114 Kg
  • Ambient Operating Temperature: -5 to 35°C, IP20 protection rating
