ABB Miniature Circuit Breaker, Type C Curve, 1 Pole, 10kA, 20A - SH201M-C20

Description for ABB Miniature Circuit Breaker, Type C Curve, 1 Pole, 10kA, 20A - SH201M-C20

The ABB SH201M-C20 Miniature Circuit Breaker (MCB) provides reliable circuit protection with its advanced current-limiting technology. Engineered with a dual-tripping mechanism, it features a delayed thermal trip for overload protection and an electromechanical trip for short circuits, ensuring comprehensive safety in electrical systems. With a 20A rating and 10kA short-circuit capacity at 230-400V AC, this 1-pole MCB is suitable for a variety of applications in residential and commercial environments. Compact and user-friendly, it includes a toggle switch with ON/OFF indication and fits easily onto DIN rails. Built for durability, it operates efficiently across a wide temperature range.

Key Specifications:

• Model: SH201M-C20, Article Number: A1A2028
• Rated Current: 20A, 1-Pole, Type C Curve
• Short-Circuit Capacity: 10kA at 230-400V AC
• Dual Tripping: Thermal for overload, Electromechanical for short-circuit
• Dimensions: 17.5 x 88 x 69mm, Color: White
• Operating Temperature: -25°C to 55°C; Storage: -40°C to 70°C
• Frequency: 50-60Hz, Power: 2.5W

Applications:
Ideal for protecting lighting, appliance, and power circuits in residential and commercial spaces, the ABB SH201M-C20 MCB offers fast, reliable response for circuit protection.
